#include<Wire.h>
// Setup stepper
#define IN1 8
#define IN2 9
#define IN3 10
#define IN4 11
//For keypad
// For stepper
int steps = 0;
boolean clockwise = true;
// For I2C and lift
const int slaveNr = 5; // Amount of slaves attached(always +1)
int floorButtonUp[slaveNr]; // Array containing button information from the slaves
int floorButtonDown[slaveNr]; // Array containing button information from the slaves
int floorButtonElevator[6] = {0,0,0,0,0,0}; // Array containing button information from the master
boolean doorOpen[slaveNr]; // If Door on floor should open, also reset floor get lift buttons
boolean liftAvailable[slaveNr]; // Array containing which IR-modules are currently triggered
int currentFloor = 0; // Current location of the elevator
boolean movingUp = true; // which direction the elevator is going
boolean moveUp = false; // Should the motor move clockwise
boolean moveDown = false; // Should the motor move counter-clockwise
void setup() {
Serial.begin(9600); // Begin serial communication
Wire.begin(); // Begin I2C communication
// Setup stepper
pinMode(IN1, OUTPUT);
pinMode(IN2, OUTPUT);
pinMode(IN3, OUTPUT);
pinMode(IN4, OUTPUT);
// this data is send to the slaves, so set to false first
for (int i = 0; i < slaveNr; i++) {
doorOpen[i] = false;
liftAvailable[i] = false;
floorButtonUp[i] = 0;
floorButtonDown[i] = 0;
}
}
void loop() {
Serial.println("getAndSendDataToAllFloors");
getAndSendDataToAllFloors(); // Retrieve which buttons are pressed and send the location of the elevator to the slaves
Serial.println("Reading elevator buttons");
readButtons(); // Read the buttons connected to the master
Serial.println("checkForMoveLift");
checkForMoveLift(); // Check to see whether the elevator needs to move
Serial.println("moveLift");
moveLift(); // Move the elevator to its destination
Serial.print("Current lift location is ");
Serial.println(currentFloor);
delay(100);
Serial.println("End of loop");
Serial.println();
}
/*********************** I2C CODE ***********************/
//===============================================================
void getAndSendDataToAllFloors() {
// For each of the connected slaves, request the currently pressed buttons and send where the elevator is and whether the door should open
// done
int i=0;
while(i != slaveNr){
Wire.requestFrom(i, 3);
while (Wire.available())
{
floorButtonUp[i] = Wire.read();
floorButtonDown[i] = Wire.read();
liftAvailable[i] = Wire.read();
}
if(liftAvailable[i] == true){
currentFloor = i;
}
Wire.beginTransmission(i);
Wire.write(currentFloor);
Wire.endTransmission();
i++;
}
}
//===============================================================
void sendLiftRelatedData(int floorIndex) {
// Sends the current floor and whether the door should open to the slave
// done (?)
int i=0;
while(i != slaveNr){
Wire.requestFrom(i, 3);
while (Wire.available())
{
Wire.beginTransmission(i);
Wire.write(currentFloor);
Wire.endTransmission();
}
i++;
}
}
//===============================================================
boolean getButtonPressedOfFloor(int floorIndex) {
// Requests the button states from a slave
// done
int i=0;
while(i != slaveNr){
Wire.requestFrom(i, 3);
while (Wire.available())
{
floorButtonUp[i] = Wire.read();
floorButtonDown[i] = Wire.read();
liftAvailable[i] = Wire.read();
}
i++;
}
}
/*********************** NON I2C CODE ***********************/
//===============================================================
void readButtons(){
// Read all the buttons connected to the master
}
void checkForMoveLift() {
// Main algorithm to check to where the lift should move
Serial.print("Check to see if current floor wants to use lift: ");
if ((floorButtonDown[currentFloor] || floorButtonUp[currentFloor] || floorButtonElevator[currentFloor]) && liftAvailable[currentFloor]) { // If there is a button pressed for the current floor and the lift is available
if (movingUp && (floorButtonUp[currentFloor] || floorButtonElevator[currentFloor])) {
// If lift is moving up and floorUp is pressed, stop at current floor
moveUp = false;
moveDown = false;
doorOpen[currentFloor] = true;
floorButtonElevator[currentFloor] = false;
Serial.println("Current floor wants to use lift");
delay(3000); // Might not be nessesary
return;
} else if (!movingUp && (floorButtonDown[currentFloor] || floorButtonElevator[currentFloor])) {
// If lift is moving down and floorDown is pressed, stop at current floor
moveUp = false;
moveDown = false;
doorOpen[currentFloor] = true;
floorButtonElevator[currentFloor] = false;
Serial.println("Current floor wants to use lift");
delay(3000); // Might not be nessesary
return;
} else if (movingUp) {
// if lift is moving up and buttonDown is pressed and there are no buttons pressed above me, stop at current floor
boolean stopHere = true;
for(int i = currentFloor + 1; i < (sizeof(floorButtonUp)/sizeof(int)); i++){
if (floorButtonUp[i] || floorButtonDown[i] || floorButtonElevator[i]){
stopHere = false;
break;
}
}
if (stopHere){
moveUp = false;
moveDown = false;
doorOpen[currentFloor] = true;
floorButtonElevator[currentFloor] = false;
Serial.println("Current floor wants to use lift");
delay(3000);
return;
}
} else if (!movingUp) {
// if lift is moving down and buttonUp is pressed and there are no buttons pressed below me, stop at current floor
boolean stopHere = true;
for(int i = currentFloor - 1; i >= 0; i--){
if (floorButtonUp[i] || floorButtonDown[i] || floorButtonElevator[i]){
stopHere = false;
break;
}
}
if (stopHere){
moveUp = false;
moveDown = false;
doorOpen[currentFloor] = true;
floorButtonElevator[currentFloor] = false;
Serial.println("Current floor wants to use lift");
delay(3000);
return;
}
} else {
Serial.println("current floor wants to go in a different direction, skipping floor");
}
} else {
Serial.println("Current floor does not want to use the lift");
doorOpen[currentFloor] = false;
}
Serial.print("Check for other floor wants to use lift: ");
if (movingUp) { // When the lift is moving up
// check floors above current floor to see if anyone wants to go up
for(int i = currentFloor; i < (sizeof(floorButtonUp)/sizeof(int)); i++) { // sizeof(int) used bacause C is a bitch https://www.arduino.cc/en/Reference/Sizeof
if (floorButtonUp[i] || floorButtonElevator[i]) {
Serial.println("A floor above me wants to go up");
moveUp = true;
moveDown = false;
movingUp = true;
return;
}
}
//====================================================================
// check floors above current floor to see if anyone wants to go down
for(int i = currentFloor; i < 0; i++) {
if (floorButtonDown[i] || floorButtonElevator[i]) {
Serial.println("A floor above me wants to go down");
moveUp = true;
moveDown = false;
movingUp = false;
return;
}
}
//=============================================================================
// check floor below current floor to see if anyone wants to go down
for(int i = currentFloor; i >= 0; i--) {
if (floorButtonDown[i] || floorButtonElevator[i]) {
Serial.println("A floor below me wants to go up");
moveUp = false;
moveDown = true;
movingUp = false;
return;
}
}
// check floors below current floor to see if anyone wants to go up
for(int i = currentFloor; i >= 0; i--) {
if (floorButtonUp[i] || floorButtonElevator[i]) {
Serial.println("A floor below me wants to go down");
moveUp = false;
moveDown = true;
movingUp = false;
return;
}
}
Serial.println("Nothing wants to use lift");
} else if (!movingUp) { // When the lift is moving down
// check floors below current floor to see if anyone wants to go up
for(int i = currentFloor; i >= 0; i--) {
if (floorButtonUp[i] || floorButtonElevator[i]) {
Serial.println("A floor below me wants to go up");
moveUp = false;
moveDown = true;
movingUp = false;
return;
}
}
// check floor below current floor to see if anyone wants to go down
for (int i = currentFloor; i >= 0; i--) {
if (floorButtonDown[i] || floorButtonElevator[i]) {
Serial.println("A floor below me wants to go down");
moveUp = false;
moveDown = true;
movingUp = false;
return;
}
}
//===============================================================
// check floors above current floor to see if anyone wants to go down
for (int i = currentFloor; i < (sizeof(floorButtonUp)/sizeof(int)); i++) {
if (floorButtonDown[i] || floorButtonElevator[i]) {
Serial.println("A floor above me wants to go dpwn");
moveUp = true;
moveDown = false;
movingUp = true;
return;
}
}
//===============================================================
// check floors above current floor to see if anyone wants to go up
for (int i = currentFloor; i < (sizeof(floorButtonUp)/sizeof(int)); i++) {
if (floorButtonUp[i] || floorButtonElevator[i]) {
Serial.println("A floor above me wants to go up");
moveUp = true;
moveDown = false;
movingUp = true;
return;
}
}
}
Serial.println("Nothing wants to use lift");
moveUp = false;
moveDown = false;
}
void moveLift() {
// Controls the lift controller
if (moveUp) {
Serial.println("going up");
liftController(true);
} else if (moveDown) {
Serial.println("going down");
liftController(false);
}
}
void liftController(boolean up) {
// Controls how many the stepping motor should rotate
clockwise = !up;
if(floorButtonElevator[5]){ //When the emergency button is pressed, stop moving the motor untill the arduino resets
return;
}
for (int i = 0; i < 1000; i++) { // remove or increase when needed,
// with this for loop the motor moves more between requests.
stepper();
delayMicroseconds(2000);
}
}
// http://www.nmbtc.com/step-motors/engineering/full-half-and-microstepping/
// Using two-phase fullstep
void stepper() {
// controls the steppenmotor
switch (steps) {
case 0:
digitalWrite(IN1, HIGH);
digitalWrite(IN2, HIGH);
digitalWrite(IN3, LOW);
digitalWrite(IN4, LOW);
break;
case 1:
digitalWrite(IN1, LOW);
digitalWrite(IN2, HIGH);
digitalWrite(IN3, HIGH);
digitalWrite(IN4, LOW);
break;
case 2:
digitalWrite(IN1, LOW);
digitalWrite(IN2, LOW);
digitalWrite(IN3, HIGH);
digitalWrite(IN4, HIGH);
break;
case 3:
digitalWrite(IN1, HIGH);
digitalWrite(IN2, LOW);
digitalWrite(IN3, LOW);
digitalWrite(IN4, HIGH);
break;
default:
digitalWrite(IN1, LOW);
digitalWrite(IN2, LOW);
digitalWrite(IN3, LOW);
digitalWrite(IN4, LOW);
break;
}
if (clockwise) {
steps++;
} else {
steps--;
}
if (steps > 3) {
steps = 0;
} else if (steps < 0) {
steps = 3;
}
}
